All-in-one compact design
High efficiency, low noise and high reliable gearbox
Brake available
Drive solution for mobile robot (AGV/Forklift)
8 Poles with 3 Phases
Low Cogging
High Power Density
8 Poles with 3 Phases
Low Cogging
High Power Density
| Article | Frame Size | Motor Length | Output Power | Rated Torque | Rated Current | Rated Speed | Rated Voltage |
|---|---|---|---|---|---|---|---|
 SE060AS100 | □60 mm | 101 mm | 124 W | 0.3 Nm | 4.3 A | 4000 RPM | 36 VDC |
| SE060AS200 | □60 mm | 113 mm | 223 W | 0.53 Nm | 7.7 A | 4000 RPM | 36 VDC |
| SE060AS300 | □60 mm | 141 mm | 410 W | 1.3 Nm | 10.7 A | 3000 RPM | 48 VDC |
 SE080AS100 | □80 mm | 132 mm | 411 W | 1.31 Nm | 10.7 A | 3000 RPM | 48 VDC |
| SE080AS200 | □80 mm | 153 mm | 765 W | 2.44 Nm | 19.9 A | 3000 RPM | 48 VDC |
 SEP040A(B)Q100-001 | □40 mm | 63.5 mm | 100 W | 0.32 Nm | 2.8 A | 3000 RPM | 48 VDC |
| SEP040A(B)Q050-001 | □40 mm | 49.5 mm | 50 W | 0.16 Nm | 1.5 A | 3000 RPM | 48 VDC |
 SEP060A(B)M200-001 | □60 mm | 64.5 mm | 200 W | 0.64 Nm | 11 A | 3000 RPM | 24 VDC |
| SEP060A(B)M200-002 | □60 mm | 64.5 mm | 200 W | 0.64 Nm | 6.5 A | 3000 RPM | 48 VDC |
| SEP060A(B)M400-001 | □60 mm | 84.5 mm | 400 W | 1.27 Nm | 22 A | 3000 RPM | 24 VDC |
